Product Description
CYC X1 Pro Gen 4 5000W Mid-Drive Conversion Kit
The release of Gen 4 is also to solve all the previous issues reported by our customers. We can now confidently say that we have the best and the most reliable power for mid drive conversion.
The X1 Pro Gen 4 is a high-powered mid-drive electric bike conversion kit made for extreme power, off-road, and utility use. Rated at 5000W & 250N.m.
The package includes everything you need to convert your bike except the battery:
- Motor-reduction assembly
- 219H chainring-reduction assembly
- Bicycle chainring with chainring cover
- 219H golden KMC chain
- ISIS splined bottom bracket & spindle
- 165mm/ 175mm crank arm set
- Gen 4 torque sensor
- X12 controller (5000W)
- Built-in bashguard
- Waterproof wire harness
- Motor hanger
- 3, 5, & 7mm spacers for BSA threaded 68/73/83mm version / 2x 2mm spacers for BB92 version
- SW102 (up to 52V)/ DS103 Display (up to 72V)
- Thumb throttle/ Half-twist throttle/ Full twist throttle
- Magnetic speed sensor
- Magnetic brake sensors (optional)
- User manual (ecopy)
CONTROLLER RELIABILITY AND PERFORMANCE
X1 PRO gen 4 is now paired with the X-series controller which makes a day and night difference than the previous models. Both the PAS and throttle experience are refined. The following list of issues are addressed with the X-series controller.
- High Initial torque
- Peak power
- Maximum reliability
- No cut-out with full power in bumpy terrain
- Instant throttle response
- Refined torque sensor tuning
- Simplified app
- Fully programmable via display, so using the app is not mandatory
- Plug-and-play
ROTOR CORE & MOTOR
With mechanically retained magnets inside the CYC motors, they are designed to reach high RPMs without failing under heat stress.
Not only are the magnets mechanically secured but CYC used high grade quality magnets that can withstand up to 180 degrees Celsius. Much more than the motor will reach during your ride allowing for ease of mind during any conditions.
The X1 PRO motor is equipped with a SPM rotor to optimize the efficiency and torque with the small form factor. To prevent the magnet loosening, the magnets are mechanically retained by the sleeve in the rotor. They are named the Gen 4 rotor.
ISIS SPLINED CRANKSET
Ensuring you have a durable crankset is crucial to any ebike. The new integrated torque sensing module has made it possible for us to give you back the ISIS splined crankset so you can rest at ease knowing that no matter how hard you pedal, your crankset will stay secure.
The bottom bracket bearings are now fully sealed to ensure maximum reliability with outdoor use.
*rendering of crankset with spindle visible
WATER RESISTANT
Love a muddy ride? What around rainy days or washing your bike? We've got you covered. We're making sure that our systems are up for the job.
All the previous water ingress point has been sealed properly with the upgrades. All the exposed bearings are also sealed so the systems are now safe to wash and use under heavy rain condition.
* rendering of kit with water splash
